Sigma -V series servo motor SGMAV.
Rated output: 0.05kw (50W).
Power supply voltage: AC200V.
Serial encoder: 20 bit absolute value (standard).
Design sequence: standard.
Shaft end: straight shaft with keyway, with screw (optional).
Optional: no matching.
Super power rate.
Small capacity.
Ultra low inertia
Instantaneous maximum torque (rating 300%).
Equipped with a high resolution serial encoder (20 bit) SGDV-1R6A15A
Max speed up to 6000r\/min.
Variety is complete (50W ~ 1.0kw, with hold brake).
Use example:
Semiconductor manufacturing equipment,
Placement machine,
Punch printed circuit board,
Robot，
Handling machinery，
Food processing machinery.
Rating and specifications:
Rated time: continuous.
Vibration level: V15.
Insulation resistance: DC500V, 10M, or above.
Using ambient temperature: 0 ~ 40 degrees C.
Excitation mode: permanent magnet type.
Installation method: flange type.
Heat resistance grade: B.
Insulation withstand voltage: AC1500V1 minutes.
Protection mode: fully enclosed self cooling type IP65 (except shaft through part).
The use of environmental humidity: 20 ~ 80% (not dew).
Connection mode: direct connection.
Rotation direction: clockwise direction (CCW) rotation at the load side under the direction of rotationServo driver SGD7S.
Maximum applicable motor capacity: 3.0kW.
Voltage: three phase AC200V.
Interface: MECHATROLINK-II communication command type.
Design sequence: A.
Hardware options: paint.
Performance excellence.
The performance and speed of the device can be improved.
Upgrade free adjustment function.
Without adjusting the operation, no vibration can be achieved.
To ensure that the procedures and parameters of the previous product compatibility.
After replacement of the product, can easily improve the performance of the device.
Sigma -7 series has rich models and related products.
Customers can easily build the system.
From selection to maintenance, rich service content.
Especially when the servo system is in trouble,
Can immediately grasp the product information in the field.
It is helpful to the servo performance of ultra high speed and ultra precision control.
Maximize the performance of the device, to solve the problem
SGDV-1R6A15A Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=SGDV-1R6A15A&select=5
