Equipped with DeviceNet communication function type servo unit (external power supply drive type)
Maximum applicable motor capacity: 0.4kw.
Power supply voltage: single phase AC100V.
Interface: instruction selection and installation (linear servo motor).
Matching (hardware): paint.
Matching (software): standard.
Matching (parameter): standard.
Optional modules: DeviceNet module (external power driver) + full closed loop module SGMGH-75ACC6C
Communication specifications for DeviceNet based on open field network.
The combination of the DeviceNet controller and the V can be used to implement motion control in a simple way.
Can make use of the city''s rich DeviceNet support software.
Can use the upper controller to manage the servo information.
Through the network from the host controller to monitor the running status of the servo drive, alarm information.
Using the upper controller to manage the servo information, which can improve the maintenance (shorten the debugging time, improve the efficiency of maintenance operations).
Save wiring, reduce the cost and improve the reliability.
Because the upper controller and the servo unit are connected through the communication network, the connection is greatly saved.
Built in rich positioning function.
Can be from the upper controller (PLC or computer) to carry out a variety of simple positioning action.
Equipped with simple positioning, continuous rotation, and return to the origin of continuous rotary motion positioning, running and other rich positioning function.Servo motor type SGMPH (speed: 3000r\/min).
Power: 0.4kw.
Power supply voltage: single phase AC200V.
Serial encoder: 13 bit relative value.
Design sequence: Waterproof standard IP67.
Shaft end: straight shaft without key.
Optional parts: with DC24V brake.
Partial flat series: the need to install the servo motor in a small space.
Flexible user system.
For you to build the best system to enrich the product line to support you.
Products with single phase 200V, single phase 100V, three-phase 200V,
And for the absolute value encoder, a variety of motor with brake, belt speed reducer.
And then, because of its compliance with international standards, in the world can be assured that the use of.
Smooth running, there is a very seasonal rate of observation and control,
The speed fluctuation of the motor is greatly reduced, and the speed of the motor can be smoothly operated
SGMGH-75ACC6C Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=SGMGH-75ACC6C&select=5
