Sigma -v series servo unit SGDV.
Maximum applicable motor capacity: 5kw.
Power supply voltage: three phase AC400V.
Design sequence: A type.
Interface: MECHATROLINK- III communication command type (linear servo motor).
Optional (hardware): DB resistance external type.
Realize real time communication
With the maximum transmission speed of 100Mbps and the set of communication cycle 125S ~ 4ms, to achieve a more than 62 stations of the high speed control SGM7P-01AFE2E
Through the high speed of communication, can send and receive all kinds of control information in real time.
Contribute to cost savings
A maximum of 62 stations can be connected to the communication line, can significantly reduce wiring costs and time.
The command connector of the upper controller only needs 1,
Pulse generator for D/A converter or position instruction without speed / torque command.
High precision motion control is realized.
In addition to torque, position and speed control, but also to achieve high precision synchronization phase control.
Because the control mode can be switched on line, the complicated mechanical action can be realized more effectively and smoothly.Servo motor type SGMPH (speed: 3000r\/min).
Power: 0.2kw.
Power supply voltage: single phase AC200V.
Serial encoder: 16 bit relative value.
Design sequence: Waterproof standard IP67.
Shaft end: straight shaft with screw key.
Optional parts: with oil seal.
Partial flat series: the need to install the servo motor in a small space.
Flexible user system.
For you to build the best system to enrich the product line to support you.
Products with single phase 200V, single phase 100V, three-phase 200V,
And for the absolute value encoder, a variety of motor with brake, belt speed reducer.
And then, because of its compliance with international standards, in the world can be assured that the use of.
Smooth running, there is a very seasonal rate of observation and control,
The speed fluctuation of the motor is greatly reduced, and the speed of the motor can be smoothly operated
SGM7P-01AFE2E Operation manual/Instructions/Model selection sample download link: /searchDownload.html?Search=SGM7P-01AFE2E&select=5
